FLOW PATTERN TESTER -700
FLOW PATTERN TESTER -700
FPT – 700 is non-contaminating fog generator that can produce very high purity fog for airflow visualization test in clean rooms & high concentration of water aerosols (Atomized particle size 1-10μm on 80%) and which will leave no residue contaminants when droplet of water evaporates in side cleanroom. This product is widely accepted to Pharmaceutical, Healthcare and Semiconductor industries.
Features and Benefits
- Portable and exquisite.
- Used for ISO-5 to ISO-8 in Cleanroom, vial tunnels, LAFW, BSC, Isolators, etc.
- Very insignificant warm-up time required (i.e. <1 minute).
- Easy to produce curtain-shaped fog by using fog wand, which helps check laminar air flow pattern by covering the maximum area of the HEPA filter at a time.
- Can use a maximum extendable flexible grooved milky white hosepipe of 10ft.
- Low noise (i.e. ≤ 50dB).
- Ultrapure foggers with absolute non-contamination; no emission of toxic gases.
- Cool fog output.
- No residual.
- Fog has good controllability.
- Air volume is adjustable.
- Visual indicators for airflow, atomization & low water level.
- Auto atomization switch off/cut off if water level is low.
- Water tank volume: 5 liters.
- Water capacity max. fill level: 3.5 liters.
- Fog medium impedance: 16 to 64 MΩ (Distilled Water or Filtered WFI, i.e., Water for Injection).
- Fog medium conductivity: 0.15 – 1.00 ms/cm.
- Fog output rate: 0.95 m³/min.
- Aerosol size distribution: 1 -10 μm.
- Continual fogging times: 40 minutes.
- Water consumption: 25 to 70 ml/min.
- Material of construction: Stainless Steel SS304.
Applications
- Cleanroom Laminar Air Flow Testing.
- Laminar Air Flow Workstations Testing.
- Airflow Balance Testing.
- Pressure balancing of inside & outside of the cleanroom testing.
- Chemical processing equipment exhausts system testing.
- Personal safety evacuation system testing.
- Wet cleaning exhaust system optimization.
